Building Docker Images with Kaniko Pushing to Google Container Registry (GCR)

To push to Google Container Registry (GCR) we need to login to Google Cloud and mount our local $HOME/.config/gcloud containing our credentials into the kaniko container so it can push to GCR. GCR does support caching and so it will push the intermediate layers to gcr.io/$PROJECT/kaniko-demo/cache:_some_large_uuid_ to be reused in subsequent builds.

git clone https://github.com/carlossg/kaniko-demo.git
cd kaniko-demo

gcloud auth application-default login # get the Google Cloud credentials
PROJECT=$(gcloud config get-value project 2> /dev/null) # Your Google Cloud project id
docker run \
    -v $HOME/.config/gcloud:/root/.config/gcloud:ro \
    -v `pwd`:/workspace \
    gcr.io/kaniko-project/executor:v1.0.0 \
    --destination gcr.io/$PROJECT/kaniko-demo:kaniko-docker \
    --cache

kaniko can cache layers created by RUN commands in a remote repository. Before executing a command, kaniko checks the cache for the layer. If it exists, kaniko will pull and extract the cached layer instead of executing the command. If not, kaniko will execute the command and then push the newly created layer to the cache.

We can see in the output how kaniko uploads the intermediate layers to the cache.

INFO[0001] Resolved base name golang to build-env
INFO[0001] Retrieving image manifest golang
INFO[0001] Retrieving image golang
INFO[0004] Retrieving image manifest golang
INFO[0004] Retrieving image golang
INFO[0006] No base image, nothing to extract
INFO[0006] Built cross stage deps: map[0:[/src/bin/kaniko-demo]]
INFO[0006] Retrieving image manifest golang
INFO[0006] Retrieving image golang
INFO[0008] Retrieving image manifest golang
INFO[0008] Retrieving image golang
INFO[0010] Executing 0 build triggers
INFO[0010] Using files from context: [/workspace]
INFO[0011] Checking for cached layer gcr.io/api-project-642841493686/kaniko-demo/cache:0ab16b2e8a90e3820282b9f1ef6faf5b9a083e1fbfe8a445c36abcca00236b4f...
INFO[0011] No cached layer found for cmd RUN cd /src && make
INFO[0011] Unpacking rootfs as cmd ADD . /src requires it.
INFO[0051] Using files from context: [/workspace]
INFO[0051] ADD . /src
INFO[0051] Taking snapshot of files...
INFO[0051] RUN cd /src && make
INFO[0051] Taking snapshot of full filesystem...
INFO[0061] cmd: /bin/sh
INFO[0061] args: [-c cd /src && make]
INFO[0061] Running: [/bin/sh -c cd /src && make]
CGO_ENABLED=0 go build -ldflags '' -o bin/kaniko-demo main.go
INFO[0065] Taking snapshot of full filesystem...
INFO[0070] Pushing layer gcr.io/api-project-642841493686/kaniko-demo/cache:0ab16b2e8a90e3820282b9f1ef6faf5b9a083e1fbfe8a445c36abcca00236b4f to cache now
INFO[0144] Saving file src/bin/kaniko-demo for later use
INFO[0144] Deleting filesystem...
INFO[0145] No base image, nothing to extract
INFO[0145] Executing 0 build triggers
INFO[0145] cmd: EXPOSE
INFO[0145] Adding exposed port: 8080/tcp
INFO[0145] Checking for cached layer gcr.io/api-project-642841493686/kaniko-demo/cache:6ec16d3475b976bd7cbd41b74000c5d2543bdc2a35a635907415a0995784676d...
INFO[0146] No cached layer found for cmd COPY --from=build-env /src/bin/kaniko-demo /
INFO[0146] Unpacking rootfs as cmd COPY --from=build-env /src/bin/kaniko-demo / requires it.
INFO[0146] EXPOSE 8080
INFO[0146] cmd: EXPOSE
INFO[0146] Adding exposed port: 8080/tcp
INFO[0146] No files changed in this command, skipping snapshotting.
INFO[0146] ENTRYPOINT ["/kaniko-demo"]
INFO[0146] No files changed in this command, skipping snapshotting.
INFO[0146] COPY --from=build-env /src/bin/kaniko-demo /
INFO[0146] Taking snapshot of files...
INFO[0146] Pushing layer gcr.io/api-project-642841493686/kaniko-demo/cache:6ec16d3475b976bd7cbd41b74000c5d2543bdc2a35a635907415a0995784676d to cache now

If we run kaniko twice we can see how the cached layers are pulled instead of rebuilt.

INFO[0001] Resolved base name golang to build-env
INFO[0001] Retrieving image manifest golang
INFO[0001] Retrieving image golang
INFO[0004] Retrieving image manifest golang
INFO[0004] Retrieving image golang
INFO[0006] No base image, nothing to extract
INFO[0006] Built cross stage deps: map[0:[/src/bin/kaniko-demo]]
INFO[0006] Retrieving image manifest golang
INFO[0006] Retrieving image golang
INFO[0008] Retrieving image manifest golang
INFO[0008] Retrieving image golang
INFO[0010] Executing 0 build triggers
INFO[0010] Using files from context: [/workspace]
INFO[0010] Checking for cached layer gcr.io/api-project-642841493686/kaniko-demo/cache:0ab16b2e8a90e3820282b9f1ef6faf5b9a083e1fbfe8a445c36abcca00236b4f...
INFO[0012] Using caching version of cmd: RUN cd /src && make
INFO[0012] Unpacking rootfs as cmd ADD . /src requires it.
INFO[0049] Using files from context: [/workspace]
INFO[0049] ADD . /src
INFO[0049] Taking snapshot of files...
INFO[0049] RUN cd /src && make
INFO[0049] Found cached layer, extracting to filesystem
INFO[0051] Saving file src/bin/kaniko-demo for later use
INFO[0051] Deleting filesystem...
INFO[0052] No base image, nothing to extract
INFO[0052] Executing 0 build triggers
INFO[0052] cmd: EXPOSE
INFO[0052] Adding exposed port: 8080/tcp
INFO[0052] Checking for cached layer gcr.io/api-project-642841493686/kaniko-demo/cache:6ec16d3475b976bd7cbd41b74000c5d2543bdc2a35a635907415a0995784676d...
INFO[0054] Using caching version of cmd: COPY --from=build-env /src/bin/kaniko-demo /
INFO[0054] Skipping unpacking as no commands require it.
INFO[0054] EXPOSE 8080
INFO[0054] cmd: EXPOSE
INFO[0054] Adding exposed port: 8080/tcp
INFO[0054] No files changed in this command, skipping snapshotting.
INFO[0054] ENTRYPOINT ["/kaniko-demo"]
INFO[0054] No files changed in this command, skipping snapshotting.
INFO[0054] COPY --from=build-env /src/bin/kaniko-demo /
INFO[0054] Found cached layer, extracting to filesystem

In Kubernetes

To deploy to GCR we can use a service account and mount it as a Kubernetes secret, but when running on Google Kubernetes Engine (GKE) it is more convenient and safe to use the node pool service account.

When creating the GKE node pool the default configuration only includes read-only access to Storage API, and we need full access in order to push to GCR. This is something that we need to change under Add a new node pool – Security – Access scopes – Set access for each API – Storage – Full. Note that the scopes cannot be changed once the node pool has been created.

If the nodes have the correct service account with full storage access scope then we do not need to do anything extra on our kaniko pod, as it will be able to push to GCR just fine.

PROJECT=$(gcloud config get-value project 2> /dev/null)

cat << EOF | kubectl create -f -
apiVersion: v1
kind: Pod
metadata:
  name: kaniko-gcr
spec:
  restartPolicy: Never
  containers:
  - name: kaniko
    image: gcr.io/kaniko-project/executor:v1.0.0
    imagePullPolicy: Always
    args: ["--dockerfile=Dockerfile",
            "--context=git://github.com/carlossg/kaniko-demo.git",
            "--destination=gcr.io/${PROJECT}/kaniko-demo:latest",
            "--cache=true"]
    resources:
      limits:
        cpu: 1
        memory: 1Gi
EOF

Building Docker Images with Kaniko Pushing to Docker Registries

We can build a Docker image with kaniko and push it to Docker Hub or any other standard Docker registry.

Running kaniko from a Docker daemon does not provide much advantage over just running a docker build, but it is useful for testing or validation. It also helps understand how kaniko works and how it supports the different registries and authentication mechanisms.

git clone https://github.com/carlossg/kaniko-demo.git
cd kaniko-demo
# if you just want to test the build, no pushing
docker run \
    -v `pwd`:/workspace gcr.io/kaniko-project/executor:v1.0.0 \
    --no-push

Building by itself is not very useful, so we want to push to a remote Docker registry.

To push to DockerHub or any other username and password Docker registries we need to mount the Docker config.json file that contains the credentials. Caching will not work for DockerHub as it does not support repositories with more than 2 path sections (acme/myimage/cache), but it will work in Artifactory and maybe other registry implementations.

DOCKER_USERNAME=[...]
DOCKER_PASSWORD=[...]
AUTH=$(echo -n "${DOCKER_USERNAME}:${DOCKER_PASSWORD}" | base64)
cat << EOF > config.json
{
    "auths": {
        "https://index.docker.io/v1/": {
            "auth": "${AUTH}"
        }
    }
}
EOF
docker run \
    -v `pwd`/config.json:/kaniko/.docker/config.json:ro \
    -v `pwd`:/workspace \
    gcr.io/kaniko-project/executor:v1.0.0 \
    --destination $DOCKER_USERNAME/kaniko-demo:kaniko-docker

In Kubernetes

In Kubernetes we can manually create a pod that will do our Docker image build. We need to provide the build context, containing the same files that we would put in the directory used when building a Docker image with a Docker daemon. It should contain the Dockerfile and any other files used to build the image, ie. referenced in COPY commands.

As build context we can use multiple sources

  • GCS Bucket (as a tar.gz file)
    • gs://kaniko-bucket/path/to/context.tar.gz
  • S3 Bucket (as a tar.gz file) `
    • s3://kaniko-bucket/path/to/context.tar.gz
  • Azure Blob Storage (as a tar.gz file)
  • Local Directory, mounted in the /workspace dir as shown above
    • dir:///workspace
  • Git Repository
    • git://github.com/acme/myproject.git#refs/heads/mybranch

Depending on where we want to push to, we will also need to create the corresponding secrets and config maps.

We are going to show examples building from a git repository as it will be the most typical use case.

Deploying to Docker Hub or a Docker registry

We will need the Docker registry credentials in a config.json file, the same way that we need them to pull images from a private registry in Kubernetes.

DOCKER_USERNAME=[...]
DOCKER_PASSWORD=[...]
DOCKER_SERVER=https://index.docker.io/v1/
kubectl create secret docker-registry regcred \
    --docker-server=${DOCKER_SERVER} \
    --docker-username=${DOCKER_USERNAME} \
    --docker-password=${DOCKER_PASSWORD}

cat << EOF | kubectl create -f -
apiVersion: v1
kind: Pod
metadata:
  name: kaniko-docker
spec:
  restartPolicy: Never
  containers:
  - name: kaniko
    image: gcr.io/kaniko-project/executor:v1.0.0
    imagePullPolicy: Always
    args: ["--dockerfile=Dockerfile",
            "--context=git://github.com/carlossg/kaniko-demo.git",
            "--destination=${DOCKER_USERNAME}/kaniko-demo"]
    volumeMounts:
      - name: docker-config
        mountPath: /kaniko/.docker
    resources:
      limits:
        cpu: 1
        memory: 1Gi
  volumes:
  - name: docker-config
    projected:
      sources:
      - secret:
          name: regcred
          items:
            - key: .dockerconfigjson
              path: config.json
EOF

Building Docker Images with Kaniko

This is the first post in a series about kaniko.

kaniko is a tool to build container images from a Dockerfile, similar to docker build, but without needing a Docker daemon. kaniko builds the images inside a container, executing the Dockerfile commands in userspace, so it allows us to build the images in standard Kubernetes clusters.

This means that in a containerized environment, be it a Kubernetes cluster, a Jenkins agent running in Docker, or any other container scheduler, we no longer need to use Docker in Docker nor do the build in the host system by mounting the Docker socket, simplifying and improving the security of container image builds.

Still, kaniko does not make it safe to run untrusted container image builds, but it relies on the security features of the container runtime. If you have a minimal base image that doesn’t require permissions to unpack, and your Dockerfile doesn’t execute any commands as the root user, you can run Kaniko without root permissions.

kaniko builds the container image inside a container, so it needs a way to get the build context (the directory where the Dockerfile and any other files that we want to copy into the container are) and to push the resulting image to a registry.

The build context can be a compressed tar in a Google Cloud Storage or AWS S3 bucket, a local directory inside the kaniko container, that we need to mount ourselves, or a git repository.

kaniko can be run in Docker, Kubernetes, Google Cloud Build (sending our image build to Google Cloud), or gVisor. gVisor is an OCI sandbox runtime that provides a virtualized container environment. It provides an additional security boundary for our container image builds.

Images can be pushed to any standard Docker registry but also Google GCR and AWS ECR are directly supported.

With Docker daemon image builds (docker build) we have caching. Each layer generated by RUN commands in the Dockerfile is kept and reused if the commands don’t change. In kaniko, because the image builds happen inside a container that is gone after the build we lose anything built locally. To solve this, kaniko can push these intermediate layers resulting from RUN commands to the remote registry when using the --cache flag.

In this series I will be covering using kaniko with several container registries.

Google Container Registry Service Account Permissions

21046548While testing Jenkins X I hit an issue that puzzled me. I use Kaniko to build Docker images and push them into Google Container Registry. But the push to GCR was failing with

INFO[0000] Taking snapshot of files...
error pushing image: failed to push to destination gcr.io/myprojectid/croc-hunter:1: DENIED: Token exchange failed for project 'myprojectid'. Caller does not have permission 'storage.buckets.get'. To configure permissions, follow instructions at: https://cloud.google.com/container-registry/docs/access-control

During installation Jenkins X creates a GCP Service Account based on the name of the cluster (in my case jx-rocks) called jxkaniko-jx-rocks with roles:

  • roles/storage.admin
  • roles/storage.objectAdmin
  • roles/storage.objectCreator

More roles are added if you install Jenkins X with Vault enabled.

A key is created for the service account and added to Kubernetes as secrets/kaniko-secret containing the service account key json, which is later on mounted in the pods running Kaniko as described in their instructions.

After looking and looking the service account and roles they all seemed correct in the GCP console, but the Kaniko build was still failing. I found a stackoverflow post claiming that the permissions were cached if you had a previous service account with the same name (WAT?), so I tried with a new service account with same permissions and different name and that worked. Weird. So I created a script to replace the service account by another one and update the Kubernetes secret.

ACCOUNT=jxkaniko-jx-rocks
PROJECT_ID=myprojectid

# delete the existing service account and policy binding
gcloud -q iam service-accounts delete ${ACCOUNT}@${PROJECT_ID}.iam.gserviceaccount.com
gcloud -q projects remove-iam-policy-binding ${PROJECT_ID} --member=serviceAccount:${ACCOUNT}@${PROJECT_ID}.iam.gserviceaccount.com --role roles/storage.admin
gcloud -q projects remove-iam-policy-binding ${PROJECT_ID} --member=serviceAccount:${ACCOUNT}@${PROJECT_ID}.iam.gserviceaccount.com --role roles/storage.objectAdmin
gcloud -q projects remove-iam-policy-binding ${PROJECT_ID} --member=serviceAccount:${ACCOUNT}@${PROJECT_ID}.iam.gserviceaccount.com --role roles/storage.objectCreator

# create a new one
gcloud -q iam service-accounts create ${ACCOUNT} --display-name ${ACCOUNT}
gcloud -q projects add-iam-policy-binding ${PROJECT_ID} --member=serviceAccount:${ACCOUNT}@${PROJECT_ID}.iam.gserviceaccount.com --role roles/storage.admin
gcloud -q projects add-iam-policy-binding ${PROJECT_ID} --member=serviceAccount:${ACCOUNT}@${PROJECT_ID}.iam.gserviceaccount.com --role roles/storage.objectAdmin
gcloud -q projects add-iam-policy-binding ${PROJECT_ID} --member=serviceAccount:${ACCOUNT}@${PROJECT_ID}.iam.gserviceaccount.com --role roles/storage.objectCreator

# create a key for the service account and update the secret in Kubernetes
gcloud -q iam service-accounts keys create kaniko-secret --iam-account=${ACCOUNT}@${PROJECT_ID}.iam.gserviceaccount.com
kubectl create secret generic kaniko-secret --from-file=kaniko-secret

And it did also work, so no idea why it was failing, but at least I’ll remember now how to manually cleanup and recreate the service account.

Building Docker Images without Docker

Kaniko-Logo
Kaniko is a project launched by Google that allows building Dockerfiles without Docker or the Docker daemon.

Kaniko can be used inside Kubernetes to build a Docker image and push it to a registry, supporting Docker registry, Google Container Registry and AWS ECR, as well as any other registry supported by Docker credential helpers.

This solution is still not safe, as containers run as root, but it is way better than mounting the Docker socket and launching containers in the host. For one there are no leaked resources or containers running outside the scheduler.

To launch Kaniko from Jenkins in Kubernetes just need an agent template that uses the debug Kaniko image (just to have cat and nohup) and a Kubernetes secret with the image registry credentials, as shown in this example pipeline.

UPDATED: some changes needed for the latest Kaniko

/**
 * This pipeline will build and deploy a Docker image with Kaniko
 * https://github.com/GoogleContainerTools/kaniko
 * without needing a Docker host
 *
 * You need to create a jenkins-docker-cfg secret with your docker config
 * as described in
 * https://kubernetes.io/docs/tasks/configure-pod-container/pull-image-private-registry/#create-a-secret-in-the-cluster-that-holds-your-authorization-token
 */

 def label = "kaniko-${UUID.randomUUID().toString()}"

 podTemplate(name: 'kaniko', label: label, yaml: """
kind: Pod
metadata:
  name: kaniko
spec:
  containers:
  - name: kaniko
    image: gcr.io/kaniko-project/executor:debug
    imagePullPolicy: Always
    command:
    - /busybox/cat
    tty: true
    volumeMounts:
      - name: jenkins-docker-cfg
        mountPath: /root
  volumes:
  - name: jenkins-docker-cfg
    projected:
      sources:
      - secret:
          name: regcred
          items:
            - key: .dockerconfigjson
              path: .docker/config.json
"""
  ) {

   node(label) {
     stage('Build with Kaniko') {
       git 'https://github.com/jenkinsci/docker-jnlp-slave.git'
       container(name: 'kaniko', shell: '/busybox/sh') {
           sh '''#!/busybox/sh
           /kaniko/executor -f `pwd`/Dockerfile -c `pwd` --insecure-skip-tls-verify --destination=mydockerregistry:5000/myorg/myimage
           '''
       }
     }
   }
 }

Pros:

  • No need to mount docker socket or have docker binary
  • No stray containers running outside of the scheduler

Cons:

  • Still not secure
  • Does not support the full Dockerfile syntax yet

Skaffold also has support for Kaniko, and can be used in your Jenkins X pipelines, which use Skaffold to abstract the image building.
